PFERD 25 x 25mm DRUM HOLDER FOR SPIRAL BANDS- 6MM SHANK - GK 2525/6 P/n 42107500
Product Description
Drum Holder 25 X 25mm- 6mm Shank - GK 2525/6
Rubber drum holder standard type = Hardness approx. 65Ð70 Shore A
Matching, reusable rubber drum holders for using abrasive spiral bands:
- Cylindrical
The high degree of fitting accuracy between the components ensures that the abrasive spiral band remains securely attached to the rubber drum holder during use.
Cylindrical rubber drum holders are designated "Holding Fixtures of Cylindrical Abrasive Sleeves" according to ISO 15637-1.
Recommendations for use:
- Abrasive spiral bands can be mounted and removed by turning them slightly to the right
- Abrasive spiral bands are easier to mount when the rubber drum holder is mounted on the tool drive
- The secure attachment of the abrasive spiral band is only guaranteed if the minimum rotational speed is observed
- Abrasive spiral bands achieve their best performance at a recommended cutting speed of 20Ð30 m/s
- Use grinding oil that is suitable for the material in order to significantly increase the tool life and the abrasive performance of the tools.
Safety notes:
- The maximum permitted peripheral speed is 30 m/s
- For safety reasons, it is imperative to remain within the stated maximum permitted rotational speed at all times
- Do not allow abrasive spiral bands to protrude beyond the rubber body
Specifications
Size : 25 x 25mm
Shank : 6mm
