UNIMIG RAZOR™ ARC 180 Welder P/n U13005
This powerful, professional STICK (MMA) machine is designed to be taken on the worksite or the workshop.
- Packed full of advanced features including hot start, arc force and anti-stick
- Capable of DC Lift Arc TIG for more versatility
- A 5-year warranty to reflect our confidence in this machine
Product No: U13005
MACHINE SPECIFICATIONS
- PRIMARY INPUT VOLTAGE: 240V Single Phase
- SUPPLY PLUG: 15 AMP
- Ieff (A): 14.7
- RATED OUTPUT: 20A/20.8V - 180A/27.2V
- NO LOAD VOLTAGE (V): 78
- PROTECTION CLASS: IP23S
- INSULATION CLASS: H
- MINIMUM GENERATOR (kVA): 10.0
- DINSE CONNECTOR: 35/50
- STANDARD: AS/NZ60974-1
- SUITABLE MATERIAL: TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze / MMA: Mild Steel, Stainless Steel, Cast Iron
- WARRANTY (Years): 5
TIG SPECIFICATIONS
- TIG FUNCTION TYPE: DC Lift Arc
- TIG WELDING CURRENT RANGE: 10-180A
- TIG DUTY CYCLE @ 40°C: 25% @ 180A, 60% @ 116A, 100% @ 90A
- TIG WELDING THICKNESS RANGE: 1-6mm
STICK SPECIFICATIONS
- STICK WELDING CURRENT RANGE: 20-180A
- STICK DUTY CYCLE @ 40°C: 20% @ 180A, 60% @ 104A, 100% @ 81A
- STICK ELECTRODE RANGE: 2.5-4.0mm
- STICK WELDING THICKNESS RANGE: 2-10mm
- Size & Weight
- DIMENSIONS (mm): 370×125×255 mm
- WEIGHT (kg): 5.8
- MACHINE FEATURES: VRD: YES
- Package Contents
- RAZOR ARC 180 PFC Welder
- 4m Twist Lock Electrode Holder
- 4m 300 Amp Earth Clamp & Lead
- Operating Manual
